AMD A8-5557M
Published: (last update )
| Core | |
|---|---|
| Code name | Richland (4C) |
| Base clock | 2100 MHz |
| Turbo full / half / single | 3100 | 3100 | 3100 MHz |
| Base multiplier | 21× |
| Technology | 32 nm |
| Transistors | 1303 million |
| Die size | 246 mm2 |
| Density | 5.30 M / mm2 |
| Cores / threads | 4 / 4 |
| Stepping | RL-A1 |
| Cache | |
| L1 data cache | 4 × 16 kB |
| L1 inst. cache | 2 × 64 kB |
| L2 cache | 2 × 2048 kB |
| L2 cache type | On-die, full speed |
| L3 cache | - |
| L3 cache type | - |
| Instructions | |
|---|---|
| Basic inst. | x86, x87, MMX(+), SSE |
| Extended inst. | SSE2, (S)SSE3 |
| Extended inst. 2 | x86-64, SSE(4.1, 4.2, 4a) |
| Extended inst. 3 | AMD-V, AES-NI, AVX |
| Extended inst. 4 | FMA3, FMA4, XOP |
| Extended inst. 5 | |
| The CPU | |
| Bus type | UMI, 100 MHz |
| Bus bandwith | - |
| Socket | Socket BGA827 |
| Package | 827 ball lidless micro-BGA |
| Package size | 31 x 27 mm |
| Manufacture date | 16th week of 2013 |
| Voltage | - |
| TDP | 35 W |
| Memory controller | DDR3 1600, 128 bit |
| Integrated VGA | - |
| Release date | 2013 |
