nVidia Quadro FX 5600
Published: (last update )
| GPU | |
|---|---|
| GPU type | G80 |
| Manufacturing process | 90 nm |
| Transistors | 681 million |
| Die size | 484 mm2 |
| Density | 1.41 M / mm2 |
| ROPs | 24 |
| TMUs | 32 |
| Pixel shaders | - |
| Vertex shaders | - |
| Unified shaders | 128 |
| Clock | 600 MHz |
| Pixel fillrate | 14 400 MP/s |
| Texel fillrate | 19 200 MT/s |
| SP gigaflops | 518 |
| DP gigaflops | - |
| DirectX | 10 |
| OpenGL | 3.3 |
| OpenCL / Compute ver. | 1.1 / 1.0 |
| Memory | |
|---|---|
| Capacity | 1 536 MB |
| Type | GDDR3 |
| Clock | 1 600 MHz |
| Bus width | 384 bit |
| Bandwith | 76 800 MB/s |
| Rated speed | - |
| Brand | - |
| The card | |
| Manufacturer | nVidia |
| Interface | PCI-E x16 |
| Interface bandwith | 4 096 MB/s |
| TDP | 171 W |
| Analog I/O ports | 2 × DVI-I |
| Digital I/O ports | 2 × DVI-I |
| Independent screens | 2 |
| Manufacture date | - |
| Release date | 2007 |
